The temperature sensing element of the bimetallic thermometer adopts a multi-turn straight spiral bimetallicstrip. One end is fixed, and the other end (free end) is connected to the mandrel. The pointer of the axial typethermometer is directly installed on the mandrel. The radial type structure indicator needle is connected to themandrel through an angle spring. When the temperature changes, the free end of the temperature sensingelement rotates, and the pointer is driven by the mandrel to indicate the change value of the temperature of themeasured medium on the dial. The electric contact thermometer, the pointer is equipped with a moving contact, and the fixed contact isinstalled on the set pointer. The pointer contact rotates with the temperature change. When the temperaturereaches or exceeds the set value, the contact closes and sends a signal to achieve the purpose of automaticcontrol and alarm.

1. The thermometer is of three types: axial type, radial type, and 135°. 2. The accuracy level of the thermometer is level 1 and level 1.5. 3. The measurement range of the thermometer is shown in Table 1. 4. The time constant of the thermometer does not exceed 40S. 5. The material of the protective tube is 1Cr18Ni9Ti stainless steel and molybdenum dititanium, and the nominalpressure it can withstand is 6.4MaP. 6. Thermometers are divided into three types: ordinary type, outdoor type, and anti-corrosion type. 7. The contacts of the thermometer are upper and lower limits, single limit, and double upper limit (all normallyopen). 8. Contact rated power: 10VA (non-inductive load). Maximum working voltage: 220V. Maximum working current: 1A. 9. The ambient temperature for the indicator head is -40~85℃. 10. The ambient humidity for the indicator head is 5~100%.
